DTOP距离丈量模组

所属分类：智能传感

产品卖点：

距离丈量模组是一种基于DTOF技术，通过发射一束短脉冲的激光，并丈量该光束从发射到被指标物体反射回接管器的功夫，从而推算出指标物体与丈量设备之间的距离。利用888集团自主研发的SPAD和怪异的ToF采集与处置技术，可实现最大4米的精确距离丈量，精确到仅2mm误差。合用于智能家居设备如饮水机、咖啡机等的液位检测、机械人导航等

? 产品特点

? 体积幼，IP67防水防尘，装置方便

? 激光Vcsel，光学抗滋扰能力强

? 切合1类人眼安全尺度

? 精准丈量液体表表高度

? 感应距离可按需要配置

产品详情

? 规格参数

工作电压	DC 5V（4-18V）
工作电流	22-28 mA
感应距离	10-200mm（±5mm）
照度	400 Lux（可调光）
输出方式	10Hz脉冲式输出
防水等级	IP67
工作环境	-40℃~85℃ , 0%RH~85%RH

? 利用场景
